Switch 24 PoE

175.500 KDRequest quote

1 / 6

A 24-port, Layer 2 PoE switch with a fanless cooling system.

175.500 KD

Available on request for projects

Supplied and installed as part of your project. Send your requirement for a quotation.

Request a quotation Call

Need it installed? Get a site quote

Pay with

Installation, warranty & supportNetwork switch configuration installation: 10–50 KWD per point · 1-year hardware warranty

Custom orders, pre-order products and project orders are planned with you as part of the order. Any visit or consultation is quoted with the project.

Licensed InstallerKuwait CoveragePost-Install Support

Expert Installation

Certified engineers on-site

Warranty Covered

Manufacturer warranty

Fast Deployment

Quick turnaround

Ongoing Support

AMC & technical support available

Who This Is Built For

Features	(16) GbE PoE+, (8) GbE ports(2) 1G SFP ports95W total PoE availabilityFanless, silent cooling

Technical Specifications

Weight: Without mounting brackets: 3 kg (6.6 lb), With mounting brackets: 3.1 kg (6.8 lb)
LLDP-MED: Yes
Dimensions: 442 x 200 x 44 mm (17.4 x 7.9 x 1.7")
Management: Ethernet, AR
STP & RSTP: Yes
Voice VLAN: Yes
Form Factor: Rack mount (1U)
LCM Display: 1.3" touchscreen
Flow Control: Yes
Jumbo Frames: Yes
Power Method: Universal input, 100–240V AC, 50/60 Hz
Power Supply: AC/DC, internal, 120W
IGMP Snooping: Yes
Storm Control: Yes
802.1X Control: Yes
ESD Protection: Air: ± 16kV, contact: ± 12kV
Mount Material: SGCC steel
NDAA Compliant: Yes
Port Isolation: Yes
Port Mirroring: Yes
Forwarding Rate: 39 Mpps
Loop Protection: Yes
Max. Po E Output: Up to PoE+
Supported VLANs: 1,000
Heat Dissipation: 85.3 BTU/hr (Excluding PoE Output)
Egress Rate Limit: Yes
Po E Ports · Po E+: 16
Enclosure Material: SGCC steel
Packet Buffer Size: 0.5 MB
Power Input Method: AC input
Switching Capacity: 52 Gbps
Access Lists · MAC: 128
Access Lists · IPv4: 128
MAC Address Blocking: Yes
Supported Rack Depth: 400~1200 mm (15.7-47.2")
LACP Port Aggregation: Yes
Port Layout · 1G SFP: 2 (1G)
MAC Address Table Size: 8,000
Max. Power Consumption: 25W (Excluding PoE output), 120W (Including PoE Output)
Total Po E Availability: 95W
Supported Voltage Range: 100–240V AC
DHCP Snooping & Guarding: Yes
Virtual Network Override: Yes
Port Layout · 1 Gb E RJ45: 24 (16 PoE+) (1G/100M/10M)
Ambient Operating Humidity: 10 to 90% noncondensing
MAC-Based Port Restriction: Yes
Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
Total Non-Blocking Throughput: 26 Gbps
IP-Based ACLs & Network Isolation: Yes
MAC-Based ACLs & Device Isolation: Yes
Multicast & Broadcast Rate Limiting: Yes
Max. Po E Wattage Per Port By PSE · Po E: 15.4W
Max. Po E Wattage Per Port By PSE · Po E+: 32W
Application Requirements · Uni Fi Network: Version 7.2.94 and later
Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
