Access Door Hub

93.000 KDOrder now

1 / 7

A single-door mechanism that provides complete entry and exit control via connected Access Readers.

93.000 KD

Available on Project Basis

Supply confirmed upon project scope — contact us to begin

Order on WhatsApp Call

Need it installed? Get a site quote

Pay with

Licensed InstallerKuwait CoveragePost-Install Support

Expert Installation

Certified engineers on-site

Warranty Covered

Manufacturer warranty

Fast Deployment

Quick turnaround

Ongoing Support

AMC & technical support available

Who This Is Built For

Features	(2) Lock terminals (12V and Dry)(2) AUX terminals for an external siren and automatic door opener(4) Additional inputs (sensors and buttons)Connect and power using PoE++Connect to two UniFi Access readers and two UniFi Protect camera or UniFi Protect Chime

Technical Specifications

Weight: 363 g (12.8 oz)
Buttons: (1) Factory reset
Mounting: DIN-rail (Included)
Dimensions: 174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3")
Power Method: PoE++, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
UL 294 Level: Destructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I
Digital Input: Request to exit, request to enter, remote release, door position sensor
Po E Interface: (1) PoE++ input, 50V DC, 1A (4) PoE+ outputs, 50V DC, 30W per port (Max 45W aggregated)
Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Mount Material: Polycarbonate
NDAA Compliant: Yes
Input Terminals: (2) Door exit request (1) Door position (1) Emergency
Supported Doors: 1
Dry Output Relay: Lock: 30V DC, 1A, Aux: 30V DC, 1A
UL 294 Statement: Compliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294., The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
Enclosure Material: Polycarbonate
Maximum User Count: 6,000
Networking Interface: (5) 10/100/1000 Base-T
Powered Output Relay: Lock: 12V DC, 1A, Aux: 12V DC, 0.33A, 12V DC, 0.33A
Indoor And Outdoor Use: Indoor only
Management Application: Access
Max. Power Consumption: 30W (Without PoE output), 50W (With PoE output)
CAN/ULC-60839-11-1 Grade: Grade assignment: 1
Po E Cabling Requirements: Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site., The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.
Ambient Operating Humidity: 5 to 95% noncondensing
Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
Recommend Max. Cable Length · Other Locks (1A): 24 AWG length: 9 m (30 ft), 22 AWG length: 15 m (49 ft), 20 AWG length: 24 m (79 ft), 18 UACC-Cable-DoorLockRelay length: 36 m (118 ft)
Document Number, And Issue Date And/Or Revision Level: UA-Hub-Door002, V01
Recommend Max. Cable Length · UA-Lock-Electric (400m A): 24 AWG length: 25 m (82 ft), 22 AWG length: 42 m (138 ft), 20 AWG length: 66 m (217 ft), 18 UACC-Cable-DoorLockRelay length: 100 m (328 ft)
Recommend Max. Cable Length · UA-Lock-Magnetic-270kg (800m A): 24 AWG length: 12 m (39 ft), 22 AWG length: 20 m (66 ft), 20 AWG length: 30 m (98 ft), 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft)
Recommend Max. Cable Length · UA-Lock-Magnetic-540kg (500m A): 24 AWG length: 20 m (66 ft), 22 AWG length: 32 m (105 ft), 20 AWG length: 51 m (167 ft), 18 UACC-Cable-DoorLockRelay length: 80 m (262 ft)
