Ubiquiti Access Fail-Secure Strike Lock (15 mm) (UACC-Lock-Strike-Secure-15mm)

Access Fail-Secure Strike Lock (15 mm)
1 / 8

The Ubiquiti UniFi Access Fail-Secure Strike Lock is a 12 V electric strike with 1,200 kg holding force and a built-in door-status contact, for wooden and metal doors.

Ubiquiti UACC-Lock-Strike-Secure-15mm price in Kuwait

Ships to order
41.500 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Model
UACC-Lock-Strike-Secure-15mm
Warranty
1-year warranty

About the Ubiquiti UACC-Lock-Strike-Secure-15mm

An electric strike replaces the fixed plate in the door frame where the latch catches, so the door stays locked from outside until the strike releases it. This UniFi model is fail-secure: with no power it stays locked (so a power cut does not unlock the door from outside), while the door can still be opened from the inside by the handle. That is the right choice for most office and storeroom doors, but check fire-safety rules for escape routes, which often require fail-safe locks.

The strike holds with 1,200 kg of force and is built from a zinc alloy body, stainless latches and an aluminium front plate, supplied with short and long plates for different frames. It mounts in a recess cut in the door frame, fits a single wooden or metal door, and runs on 12 V DC at 400 mA, which a UniFi Access hub can supply directly.

A built-in dry-contact switch reports whether the door is open or closed, so Access can log it without a separate door sensor. Its operating range is -10 to 60 °C, and the lock body measures 80 x 40 x 35 mm.

Ubiquiti UACC-Lock-Strike-Secure-15mm specifications

Power
12 V DC ±10%, 400 mA ±10%
Mounting
Door-frame recess mount
Door Type
Single door, wooden or metal
Lock Body
80 x 40 x 35 mm, 185 g
Lock Type
Fail-secure electric strike
Materials
Zinc alloy body, aluminium front plate, stainless steel latches
Door Status
Dry contact, 30 V DC 0.1 A max
Holding Force
1,200 kg
Operating Temperature
-10 to 60 °C
Model
Ubiquiti UniFi UACC-Lock-Strike-Secure-15mm
NDAA Compliant
Yes

Ubiquiti UACC-Lock-Strike-Secure-15mm features

  • Fail-secure electric strike
  • 1,200 kg holding force
  • 12 V 400 mA
  • Built-in door-status switch
  • Short and long front plates

Best suited for

Office and storeroom doors with UniFi Access that should stay locked during a power cut.

Ubiquiti UACC-Lock-Strike-Secure-15mm downloads

Ubiquiti UACC-Lock-Strike-Secure-15mm questions

What does fail-secure mean on the UniFi strike lock?

The door stays locked from outside if power is lost; it can still be opened from inside by the handle.

Can a UniFi Access hub power this lock?

Yes. It needs 12 V DC at 400 mA, within the hub's lock output.
