Akuvox E12W Wi-Fi SIP Video Door Phone

1 / 2

A slim one-button SIP video door phone with built-in Wi-Fi, a 2MP wide-angle camera and a card reader, for the door or gate of a house or flat.

Akuvox E12W price in Kuwait

Available

75.000 KD

Available with installation only

Free remote support included

A person replies within 4–8 working hours

Brand: Akuvox
Model: E12W
Warranty: 1-year warranty

Installation terms KNET accepted

About the Akuvox E12W

The Akuvox E12W is the Wi-Fi model of Akuvox's slim E12 door phone. When the visitor presses the single call button, the call rings on an Akuvox indoor monitor, an IP phone or the SmartPlus app on your mobile, with live video from the 2MP camera. The lens covers 123° across and 69° top to bottom, so a person standing close to the door still fits in the picture, and white LEDs switch on in the dark (minimum illumination 0.1 lux).

The door opens in several ways: from the monitor or the app during a call, with a 13.56 MHz Mifare or DESFire (EV1/EV2/EV3) card or tag on the reader, with an Android phone over NFC, or over Bluetooth 5.0 with the Akuvox app. One relay drives the electric lock or the gate motor, and two inputs take an exit button and a door sensor. The unit stores up to 1,000 users and 5,000 cards.

The difference from the E12S is the Wi-Fi radio. Where no network cable reaches the gate, the E12W joins the house Wi-Fi and only needs a 12V DC supply at the door; where a cable does reach it, it runs on 802.3af PoE like the E12S. On the current hardware (datasheet V4.0) the Wi-Fi is 802.11a/b/g/n/ac/ax on 2.4 GHz and 5 GHz; earlier units were 2.4 GHz only. A wired connection stays the steadier choice for video, so Wi-Fi is best kept for doors where cabling is not possible.

The panel is plastic, rated IP65 against dust and water jets, surface-mounted, 146 × 70 × 23 mm, and rated for -40 °C to +60 °C. A tamper alarm reports if it is pulled off the wall. It speaks SIP and ONVIF, so an NVR can record its camera, and a Wiegand port connects it to an access control panel.

Akuvox E12W specifications

Camera: 2MP, 1/2.7" CMOS
Night Lighting: White LEDs, auto night mode, minimum illumination 0.1 lux
Storage Slot: 1 × TF (microSD) card slot
Ethernet: 1 × RJ45, 10/100 Mbps
Wi-Fi: IEEE 802.11a/b/g/n/ac/ax, 2.4 GHz and 5 GHz (datasheet V4.0; earlier units 2.4 GHz only)
Video Codec: H.264
Audio Codecs: G.711a, G.711μ, G.722
Power Supply: 802.3af PoE, or 12V DC when not using PoE
Ingress Protection: IP65
Type: One-button SIP video door phone with Wi-Fi
Audio: Two-way, echo cancellation
Inputs: 2
Housing: Plastic
Wiegand: 1 port, input or output
Capacity: 1,000 users, 5,000 cards
Mounting: Surface, on the wall
Bluetooth: BLE, Bluetooth 5.0
Protocols: SIP v1 / v2, ONVIF, RTSP, HTTP/HTTPS
Call Button: 1
Card Reader: 13.56 MHz: Mifare and DESFire (EV1/EV2/EV3) cards; NFC with Android phones
Tamper Alarm: Yes
Relay Outputs: 1
Viewing Angle: 123° (H) / 69° (V)
Operating System: Linux
Video Resolution: Up to 1920 × 1080 at 30 fps
Operating Temperature: -40 °C to +60 °C
Model: E12W
Dimensions: 146 × 70 × 23 mm (H × W × D)
Operating Humidity: 10% to 90%

Akuvox E12W features

Built-in Wi-Fi for doors and gates with no network cable
2MP camera with a 123° wide-angle lens
White LED lighting for video at night
Opens with Mifare or DESFire cards, Android NFC or Bluetooth
Answer and open from an indoor monitor, an IP phone or the SmartPlus app
One relay for the lock or gate, two inputs for an exit button and door sensor
802.3af PoE when a cable is available, 12V DC otherwise
IP65 panel rated for -40 °C to +60 °C

Show all 11 features

SIP and ONVIF: works with SIP PBXs and NVRs
Wiegand port for an access control panel
Tamper alarm

Best suited for

A villa gate, house door or flat entrance where the visitor should be seen on a mobile or monitor, and where a network cable to the door is hard to run.

Compare the Akuvox E12W with similar models

Available with installation only ? Free remote support included

Specification	Akuvox E12WThis model75.000 KWD	Akuvox E12S70.000 KWD	Akuvox E12S-285.000 KWD	Akuvox E13S51.000 KWD
Camera	2MP, 1/2.7" CMOS	2MP, 1/2.7" CMOS	2MP, 1/2.7" CMOS	2MP, 1/2.8" CMOS
Type	One-button SIP video door phone with Wi-Fi	One-button SIP video door phone	One-button 2-wire IP video door phone	One-button SIP video door phone
Capacity	1,000 users, 5,000 cards	1,000 users, 5,000 cards	1,000 users, 5,000 cards	5,000 cards
Mounting	Surface, on the wall	Surface, on the wall	Surface, on the wall	Flush (in-wall) or surface (on-wall)
Protocols	SIP v1 / v2, ONVIF, RTSP, HTTP/HTTPS	SIP v1 / v2, ONVIF, RTSP, HTTP/HTTPS	SIP v1 / v2, ONVIF, RTSP, HTTP/HTTPS	SIP, ONVIF, RTSP, HTTP/HTTPS
Card Reader	13.56 MHz: Mifare and DESFire (EV1/EV2/EV3) cards; NFC…	13.56 MHz: Mifare and DESFire (EV1/EV2/EV3) cards; NFC…	13.56 MHz: Mifare and DESFire (EV1/EV2/EV3) cards; NFC…	13.56 MHz: Mifare and FeliCa cards; NFC with Android…

Same on all: Video Codec · Audio Codecs · Ingress Protection · Audio · Inputs · Housing

Akuvox E12W downloads

Datasheetakuvox.com

Akuvox E12W questions

What is the difference between the Akuvox E12W and the E12S?

Only Wi-Fi. Both have the same 2MP camera, card reader, relay and IP65 housing. The E12W adds a Wi-Fi radio, so it can join the network without a cable and run on a 12V DC supply; the E12S needs a network cable and runs on PoE.

Does the E12W still need power at the door when it uses Wi-Fi?

Yes. Wi-Fi replaces the network cable, not the power. Without a PoE cable it needs a 12V DC supply at the door.

Which cards open the door on the E12W?

13.56 MHz Mifare cards and DESFire EV1, EV2 and EV3 cards and tags. Android phones can also be used over NFC, and phones with the Akuvox app over Bluetooth. 125 kHz proximity cards are not read.
