RG-RAP1260

Ruijie Reyee RG-RAP1260 WiFi 6 Dual-Band Wall-Plate Access Point

40.000 KDRequest quote

1 / 5

Multi-port WiFi 6 (802.11ax) wall-plate access point with AX3000 performance and 5 Gigabit Ethernet ports, designed for comprehensive room connectivity in hotels and offices.

40.000 KD

Available on request for projects

Supplied and installed as part of your project. Send your requirement for a quotation.

1-year warranty

Request a quotation Call

Need it installed? Get a site quote

Pay with

Installation, warranty & supportWi-Fi access point installation: 5–25 KWD per point · 1-year hardware warranty

Custom orders, pre-order products and project orders are planned with you as part of the order. Any visit or consultation is quoted with the project.

Licensed InstallerKuwait CoveragePost-Install Support

Expert Installation

Certified engineers on-site

Warranty Covered

1-year warranty

Fast Deployment

Quick turnaround

Ongoing Support

AMC & technical support available

Who This Is Built For

Features

High throughput in a wall-plate form with up to ~2,976 Mbps AX3000 performanceMulti-port versatility with 4 LAN ports for local wired devices plus PoE-in uplinkSeamless roaming and mesh support with 802.11k/v roaming and Reyee Mesh integrationCloud and remote management via Ruijie/Reyee platform for centralized monitoringCompact form factor suitable for wall mounting in various indoor environmentsGood client support with 512 maximum clients and ~110 recommended for optimal performanceStrong antenna performance with 3dBi (2.4GHz) and 5dBi (5GHz) gainsPoE-powered deployment for simplified installation without additional wiringEnterprise-grade security with WPA3 and advanced encryption supportAI-driven optimization and automatic channel/power adjustmentMultiple SSID support for network segmentation and guest accessEasy integration with existing network infrastructure

Use Cases

Guest rooms in hotels and hospitality venues
Hotel hallways and corridors requiring wall-mounted coverage
Apartments, condos, and villas with in-wall deployment needs
Offices and meeting rooms where wall-mounted APs are preferred
Rooms with multiple network devices (TV, PC, console) benefiting from LAN ports
Retrofits in existing wall-box infrastructures
Hybrid deployments combining wall-plate and ceiling APs
Healthcare facilities requiring discreet WiFi solutions
Educational institutions with wall-mounted requirements
Multi-dwelling units (MDUs) and apartment complexes

Technical Specifications

Weight: ~0.5 kg or less
Security: WPA2 / WPA3 support, captive portal, cloud/remote management
Dimensions: 124 mm × 86 mm × 24 mm
Management: Ruijie / Reyee cloud management platform integration
Antenna Gains: 2.4 GHz ~3 dBi, 5 GHz ~5 dBi
Power Support: IEEE 802.3af / 802.3at PoE-in, Typical power consumption: ≤ ~12 W
Wi Fi Standard: IEEE 802.11ax (WiFi 6) dual-band (2.4 GHz + 5 GHz)
Ethernet Ports: 5 × 1 Gbps RJ45 ports total: 1 × PoE-in uplink, 4 × downlink LAN ports
Client Capacity: Up to 512 clients (maximum), Recommended ~110 concurrent clients
Advanced Features: Roaming support (802.11k/v), Reyee Mesh, cloud portal & AI roaming
Ingress Protection: Indoor (IP41 rating typical)
MIMO Configuration: 2×2 MU-MIMO on both bands (2.4 & 5 GHz)
Maximum Throughput: Up to ~2,976 Mbps (AX3000 class)
Antenna Configuration: Internal omnidirectional antennas
Operating Temperature: 0 °C to 40 °C
