TP-Link Omada Pro S5500-24GP4F 24-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP Slots

TP-Link Omada Pro S5500-24GP4F 24-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP Slots
1 / 3

The TP-Link Omada Pro S5500-24GP4F is a 24-port gigabit PoE+ L2+ managed switch with a 250 W budget, four gigabit SFP uplinks, static routing and ERPS ring protection.

TP-Link S5500-24GP4F price in Kuwait

Available
199.900 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Brand
TP-Link
Model
S5500-24GP4F
Warranty
1-year warranty
Other models

About the TP-Link S5500-24GP4F

The S5500-24GP4F is the entry model of TP-Link's Omada Pro access switches, the line built for larger installations managed by the Omada Pro controller. All 24 gigabit ports supply PoE+ from a 250 W budget, a fit for a floor of IP phones with some access points, or a camera system of around 15 to 20 cameras, and four gigabit SFP slots carry fibre uplinks.

Omada Pro adds zero-touch provisioning, so a switch shipped to a site configures itself from the cloud controller when it is plugged in, plus anomaly detection and management from the Omada app. It can also be run standalone through a web interface, CLI or SNMP. ERPS ring protection lets several switches be cabled in a ring that recovers quickly if one link is cut, useful on campuses and along fences.

Layer 2+ features include static routing with 48 routes, DHCP server and relay, 4K VLANs with voice VLAN and QinQ, LACP, STP/RSTP/MSTP, and IGMP and MLD snooping. Switching is 56 Gbps with an 8K MAC table. The 1U chassis has two fans and is rated for 0 to 50 °C.

TP-Link S5500-24GP4F specifications

Ports
24 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP
Forwarding Rate
41.7 Mpps
Switching Capacity
56 Gbps
PoE
802.3at/af on 24 ports, 250 W total
Power
Internal 100-240 V AC; 301.1 W maximum with 250 W of PDs
VLAN
4K VLANs, voice VLAN, MAC and protocol VLAN, QinQ
Layer
L2+ managed
Cooling
2 fans
Management
Omada Pro cloud / software controller, ZTP, web GUI, CLI, SNMP v1/v2c/v3, RMON
Resilience
ERPS, LACP, STP / RSTP / MSTP
L3 Features
Static routing (48 routes), DHCP server, DHCP relay, 32 IP interfaces
MAC Address Table
8K
Operating Temperature
0 to 50 °C
Model
TP-Link Omada Pro S5500-24GP4F
Dimensions
440 x 220 x 44 mm (1U)

TP-Link S5500-24GP4F features

  • 24 PoE+ ports, 250 W
  • 4 gigabit SFP uplinks
  • Omada Pro zero-touch provisioning
  • ERPS ring protection
  • Static routing and DHCP server

Best suited for

Office floors and mid-sized CCTV systems on Omada Pro that need PoE+ on every port.

Compare the TP-Link S5500-24GP4F with similar models

Available with installation only · Free remote support included

Specification
TP-Link S5500-24GP4FThis model199.900 KWD
Ports24 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP24 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and…8 x 100M/1G/2.5G PoE+ RJ45, 2 x 10G SFP+, RJ45 and…24 x 100M/1G/2.5G RJ45 (8 x PoE++, 16 x PoE+), 4 x 10G…
Forwarding Rate41.7 Mpps95.23 Mpps59.52 Mpps148.8 Mpps
Switching Capacity56 Gbps128 Gbps80 Gbps200 Gbps
PoE802.3at/af on 24 ports, 250 W total802.3at/af, up to 30 W per port, 384 W total802.3at/af, up to 30 W per port, 240 W total802.3bt on 8 ports (up to 60 W), 802.3at on 16 ports…
PowerInternal 100-240 V AC; 301.1 W maximum with 250 W of PDsInternal; 30.4 W without PDs, 486.2 W with 384 W of PDsInternal; 285.9 W maximum with 240 W of PDsInternal; 629.1 W maximum with 500 W of PDs
VLAN4K VLANs, voice VLAN, MAC and protocol VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, voice VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ

Same on all: Layer

TP-Link S5500-24GP4F questions

What is ERPS on the S5500-24GP4F?

Ethernet Ring Protection Switching lets switches be connected in a ring; if one link fails, traffic reroutes around the ring quickly.

Does the S5500-24GP4F need a controller?

No. It can be managed standalone by web, CLI or SNMP, or centrally with the Omada Pro controller.
