TP-Link Omada Pro S5500-48GP4XF 48-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP+ Slots

TP-Link Omada Pro S5500-48GP4XF 48-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP+ Slots
1 / 3

The TP-Link Omada Pro S5500-48GP4XF is a 48-port gigabit PoE+ L2+ switch with a 500 W budget, four 10G SFP+ uplinks and 176 Gbps non-blocking switching.

TP-Link S5500-48GP4XF price in Kuwait

Available
399.900 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Brand
TP-Link
Model
S5500-48GP4XF
Warranty
1-year warranty
Other models

About the TP-Link S5500-48GP4XF

The S5500-48GP4XF is the largest gigabit access switch in the Omada Pro S5500 family. Its 500 W PoE budget is enough to mix many phones with a good number of access points and cameras across 48 ports, and four 10G SFP+ uplinks with a non-blocking 176 Gbps fabric mean that even with every port busy, traffic reaches the core at full speed.

That makes it a natural floor switch for a busy headquarters, a hospital ward or a school building: phones, Wi-Fi and cameras on one switch, VLANs keeping them apart, and IGMP snooping with 1,000 multicast groups handling video streams. A 12 Mbit buffer and a 16K MAC table cope with dense device counts.

Management is through Omada Pro, with zero-touch provisioning and central monitoring, or standalone by web, CLI and SNMP using the RJ45 or Micro-USB console. Static routing, DHCP server and relay, private VLAN, QinQ, ERPS rings and LACP are included. With full PoE load it draws up to about 636 W, so plan the circuit and UPS; it has three fans and is rated for 0 to 40 °C.

TP-Link S5500-48GP4XF specifications

Ports
48 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and Micro-USB console
Forwarding Rate
130.94 Mpps
Switching Capacity
176 Gbps (non-blocking)
PoE
802.3at/af, up to 30 W per port, 500 W total
Power
Internal; 49.2 W without PDs, 635.7 W with 500 W of PDs
VLAN
4K VLANs, private VLAN, voice VLAN, QinQ
Layer
L2+ managed
Cooling
3 fans
Multicast
IGMP v1-v3 and MLD snooping, 1,000 groups
Management
Omada Pro controller, ZTP, web GUI, CLI, SNMP, RMON
L3 Features
Static routing (48 routes), DHCP server, DHCP relay
Packet Buffer
12 Mbit
MAC Address Table
16K
Operating Temperature
0 to 40 °C
Model
TP-Link Omada Pro S5500-48GP4XF
Dimensions
440 x 330 x 44 mm (1U)

TP-Link S5500-48GP4XF features

  • 48 PoE+ ports, 500 W
  • 4 x 10G SFP+ uplinks
  • 176 Gbps non-blocking
  • 1,000 IGMP groups
  • Omada Pro ZTP

Best suited for

Busy headquarters floors, hospital wards and school buildings mixing phones, Wi-Fi and cameras.

Compare the TP-Link S5500-48GP4XF with similar models

Available with installation only · Free remote support included

Specification
TP-Link S5500-48GP4XFThis model399.900 KWD
Ports48 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and…48 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP4 x 100M/1G/2.5G/5G/10G PoE++ RJ45, 2 x 10G SFP+, RJ45…24 x 100M/1G/2.5G RJ45 (8 x PoE++, 16 x PoE+), 4 x 10G…
Forwarding Rate130.94 Mpps77.4 Mpps89.28 Mpps148.8 Mpps
Switching Capacity176 Gbps (non-blocking)104 Gbps120 Gbps200 Gbps
PoE802.3at/af, up to 30 W per port, 500 W total802.3at/af on 48 ports, 384 W total802.3af/at/bt (Type 3), up to 60 W per port, 200 W total802.3bt on 8 ports (up to 60 W), 802.3at on 16 ports…
PowerInternal; 49.2 W without PDs, 635.7 W with 500 W of PDsInternal; 464.2 W maximum with 384 W of PDsInternal; 244.9 W maximum with 200 W of PDsInternal; 629.1 W maximum with 500 W of PDs
VLAN4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, voice VLAN, QinQ4K VLANs, private VLAN, voice VLAN4K VLANs, private VLAN, voice VLAN, QinQ

Same on all: Layer · Management

TP-Link S5500-48GP4XF questions

What is the PoE budget of the S5500-48GP4XF?

500 W across 48 PoE+ ports, up to 30 W on any one port.

Is the S5500-48GP4XF non-blocking?

Yes, its 176 Gbps capacity covers all 48 gigabit ports and four 10G uplinks at full speed.
