The TP-Link Omada Pro S5500-8MHP2XF is an 8-port 2.5G PoE+ L2+ switch with a full 240 W budget and two 10G SFP+ uplinks, built for Wi-Fi 6E and Wi-Fi 7 access points.

TP-Link S5500-8MHP2XF price in Kuwait

Available
199.900 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Brand
TP-Link
Model
S5500-8MHP2XF
Warranty
1-year warranty
Other models

About the TP-Link S5500-8MHP2XF

Modern access points such as Wi-Fi 6E and Wi-Fi 7 models have 2.5G uplinks, and a gigabit port caps them below their real speed. The S5500-8MHP2XF is designed for exactly that: eight 2.5G ports, each with PoE+ at up to 30 W and a 240 W budget that powers all eight at full draw, plus two 10G SFP+ uplinks to carry their combined traffic.

It is a compact 8-port switch in a full-width 1U chassis, which suits a ceiling-zone or floor cabinet feeding a group of high-performance access points, or a small high-speed workgroup. Switching is 80 Gbps with a 16K MAC table and a 12 Mbit buffer.

As an Omada Pro switch it supports zero-touch provisioning and central management, or standalone control through web, CLI and SNMP from the RJ45 or Micro-USB console. Static routing, DHCP server and relay, 4K VLANs, QinQ, ERPS and IGMP/MLD snooping are included. It has two fans and is rated for 0 to 50 °C.

TP-Link S5500-8MHP2XF specifications

Ports
8 x 100M/1G/2.5G PoE+ RJ45, 2 x 10G SFP+, RJ45 and Micro-USB console
Forwarding Rate
59.52 Mpps
Switching Capacity
80 Gbps
PoE
802.3at/af, up to 30 W per port, 240 W total
Power
Internal; 285.9 W maximum with 240 W of PDs
VLAN
4K VLANs, voice VLAN, QinQ
Layer
L2+ managed
Cooling
2 fans
Management
Omada Pro controller, ZTP, web GUI, CLI, SNMP, RMON
L3 Features
Static routing (48 routes), DHCP server, DHCP relay
Packet Buffer
12 Mbit
MAC Address Table
16K
Operating Temperature
0 to 50 °C
Model
TP-Link Omada Pro S5500-8MHP2XF
Dimensions
440 x 180 x 44 mm (1U)

TP-Link S5500-8MHP2XF features

  • 8 x 2.5G PoE+ ports
  • 240 W, full PoE+ on every port
  • 2 x 10G SFP+ uplinks
  • Omada Pro ZTP
  • Rated to 50 °C

Best suited for

Groups of Wi-Fi 6E or Wi-Fi 7 access points with 2.5G uplinks on an Omada Pro network.

Compare the TP-Link S5500-8MHP2XF with similar models

Available with installation only · Free remote support included

Specification
TP-Link S5500-8MHP2XFThis model199.900 KWD
Ports8 x 100M/1G/2.5G PoE+ RJ45, 2 x 10G SFP+, RJ45 and…24 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP24 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and…24 x 100M/1G/2.5G RJ45 (8 x PoE++, 16 x PoE+), 4 x 10G…
Forwarding Rate59.52 Mpps41.7 Mpps95.23 Mpps148.8 Mpps
Switching Capacity80 Gbps56 Gbps128 Gbps200 Gbps
PoE802.3at/af, up to 30 W per port, 240 W total802.3at/af on 24 ports, 250 W total802.3at/af, up to 30 W per port, 384 W total802.3bt on 8 ports (up to 60 W), 802.3at on 16 ports…
PowerInternal; 285.9 W maximum with 240 W of PDsInternal 100-240 V AC; 301.1 W maximum with 250 W of PDsInternal; 30.4 W without PDs, 486.2 W with 384 W of PDsInternal; 629.1 W maximum with 500 W of PDs
VLAN4K VLANs, voice VLAN, QinQ4K VLANs, voice VLAN, MAC and protocol VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ

Same on all: Layer

TP-Link S5500-8MHP2XF questions

Why choose 2.5G ports on the S5500-8MHP2XF?

Wi-Fi 6E and Wi-Fi 7 access points can exceed 1 Gbps; 2.5G ports let them run at full speed.

Can the S5500-8MHP2XF power all eight ports at 30 W?

Yes, its 240 W budget covers 30 W on all eight ports.
