TP-Link Omada Pro S5500-24GP4XF 24-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP+ Slots

TP-Link Omada Pro S5500-24GP4XF 24-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP+ Slots
1 / 3

The TP-Link Omada Pro S5500-24GP4XF is a 24-port gigabit PoE+ L2+ switch with a 384 W budget and four 10G SFP+ uplinks, for floors of Wi-Fi 6 access points and cameras.

TP-Link S5500-24GP4XF price in Kuwait

Available
249.900 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Brand
TP-Link
Model
S5500-24GP4XF
Warranty
1-year warranty
Other models

About the TP-Link S5500-24GP4XF

The S5500-24GP4XF takes the 24-port Omada Pro design up a level in two ways. Its PoE budget rises to 384 W, about 16 W per port with every port in use, so it can power a full floor of Wi-Fi 6 access points or a large share of cameras. And its four uplinks are 10G SFP+, so a busy floor is not choked by a gigabit link back to the core.

The fabric switches 128 Gbps at 95.2 million packets a second, with a 16K MAC table and a 12 Mbit buffer that absorbs bursts from many cameras streaming at once. Both an RJ45 and a Micro-USB console port are available for out-of-band setup.

It runs Omada Pro: zero-touch provisioning and central management in the cloud or on a software controller, with standalone web, CLI and SNMP as alternatives. Features include static routing, DHCP server and relay, 4K VLANs with private VLAN and QinQ, 1,000 IGMP groups for multicast video, ERPS rings, LACP and spanning tree. The 1U chassis has two fans and is rated for 0 to 45 °C.

TP-Link S5500-24GP4XF specifications

Ports
24 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and Micro-USB console
Forwarding Rate
95.23 Mpps
Switching Capacity
128 Gbps
PoE
802.3at/af, up to 30 W per port, 384 W total
Power
Internal; 30.4 W without PDs, 486.2 W with 384 W of PDs
VLAN
4K VLANs, private VLAN, voice VLAN, QinQ
Layer
L2+ managed
Cooling
2 fans
Multicast
IGMP v1-v3 and MLD snooping, 1,000 groups, MVR
Management
Omada Pro controller, ZTP, web GUI, CLI, SNMP, RMON
L3 Features
Static routing (48 routes), DHCP server, DHCP relay
Packet Buffer
12 Mbit
MAC Address Table
16K
Operating Temperature
0 to 45 °C
Model
TP-Link Omada Pro S5500-24GP4XF
Dimensions
440 x 330 x 44 mm (1U)

TP-Link S5500-24GP4XF features

  • 24 PoE+ ports, 384 W
  • 4 x 10G SFP+ uplinks
  • 128 Gbps, 12 Mbit buffer
  • Omada Pro ZTP
  • Private VLAN and QinQ

Best suited for

Floors of Wi-Fi 6 access points or camera-heavy sites that need 10G uplinks on Omada Pro.

Compare the TP-Link S5500-24GP4XF with similar models

Available with installation only · Free remote support included

Specification
TP-Link S5500-24GP4XFThis model249.900 KWD
Ports24 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and…24 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP24 x 100M/1G/2.5G RJ45 (8 x PoE++, 16 x PoE+), 4 x 10G…8 x 100M/1G/2.5G PoE+ RJ45, 2 x 10G SFP+, RJ45 and…
Forwarding Rate95.23 Mpps41.7 Mpps148.8 Mpps59.52 Mpps
Switching Capacity128 Gbps56 Gbps200 Gbps80 Gbps
PoE802.3at/af, up to 30 W per port, 384 W total802.3at/af on 24 ports, 250 W total802.3bt on 8 ports (up to 60 W), 802.3at on 16 ports…802.3at/af, up to 30 W per port, 240 W total
PowerInternal; 30.4 W without PDs, 486.2 W with 384 W of PDsInternal 100-240 V AC; 301.1 W maximum with 250 W of PDsInternal; 629.1 W maximum with 500 W of PDsInternal; 285.9 W maximum with 240 W of PDs
VLAN4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, voice VLAN, MAC and protocol VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, voice VLAN, QinQ

Same on all: Layer

TP-Link S5500-24GP4XF questions

S5500-24GP4F or S5500-24GP4XF?

The 24GP4XF has 384 W instead of 250 W of PoE and 10G SFP+ uplinks instead of 1G SFP.

Does the S5500-24GP4XF have a console port?

Yes, both RJ45 and Micro-USB.
