TP-Link Omada Pro S5500-48GP4F 48-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP Slots

TP-Link Omada Pro S5500-48GP4F 48-Port PoE+ Gigabit L2+ Managed Switch with 4 SFP Slots
1 / 3

The TP-Link Omada Pro S5500-48GP4F is a 48-port gigabit PoE+ L2+ managed switch with a 384 W budget and four gigabit SFP uplinks, managed by Omada Pro.

TP-Link S5500-48GP4F price in Kuwait

Available
349.900 KD

Free quotation, no obligation

Available with installation onlyFree remote support included

Brand
TP-Link
Model
S5500-48GP4F
Warranty
1-year warranty
Other models

About the TP-Link S5500-48GP4F

With 48 PoE+ ports in one rack unit, the S5500-48GP4F suits buildings with many low-power devices on one floor: a call centre full of IP phones, a hotel floor of room phones and access points, or a large CCTV system. Its 384 W budget averages 8 W across all 48 ports, ideal for phones at 3 to 7 W each with headroom for a few access points or cameras on the busier ports.

The four uplinks are gigabit SFP, which is appropriate when most traffic is voice or camera streams rather than heavy data. Switching runs at 104 Gbps with a 16K MAC table and a 12 Mbit buffer.

As part of Omada Pro it supports zero-touch provisioning, cloud or software controller management and the Omada app, and can be run on its own through web, CLI or SNMP. Its L2+ set covers static routing, DHCP server and relay, 4K VLANs with voice VLAN and QinQ, ERPS rings, LACP, STP/RSTP/MSTP and IGMP/MLD snooping. The chassis has three fans and is rated for 0 to 40 °C, so it needs a cooled comms room.

TP-Link S5500-48GP4F specifications

Ports
48 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP
Forwarding Rate
77.4 Mpps
Switching Capacity
104 Gbps
PoE
802.3at/af on 48 ports, 384 W total
Power
Internal; 464.2 W maximum with 384 W of PDs
VLAN
4K VLANs, voice VLAN, QinQ
Layer
L2+ managed
Cooling
3 fans
Management
Omada Pro controller, ZTP, web GUI, CLI, SNMP, RMON
Resilience
ERPS, LACP, STP / RSTP / MSTP
L3 Features
Static routing (48 routes), DHCP server, DHCP relay
Packet Buffer
12 Mbit
MAC Address Table
16K
Operating Temperature
0 to 40 °C
Model
TP-Link Omada Pro S5500-48GP4F
Dimensions
440 x 330 x 44 mm (1U)

TP-Link S5500-48GP4F features

  • 48 PoE+ ports, 384 W
  • 4 gigabit SFP uplinks
  • Omada Pro management
  • Voice VLAN for IP phones
  • ERPS and LACP

Best suited for

Call centres, hotel floors and large CCTV systems with many low-power PoE devices.

Compare the TP-Link S5500-48GP4F with similar models

Available with installation only · Free remote support included

Specification
TP-Link S5500-48GP4FThis model349.900 KWD
Ports48 x 10/100/1000 PoE+ RJ45, 4 x gigabit SFP48 x 10/100/1000 PoE+ RJ45, 4 x 10G SFP+, RJ45 and…4 x 100M/1G/2.5G/5G/10G PoE++ RJ45, 2 x 10G SFP+, RJ45…24 x 100M/1G/2.5G RJ45 (8 x PoE++, 16 x PoE+), 4 x 10G…
Forwarding Rate77.4 Mpps130.94 Mpps89.28 Mpps148.8 Mpps
Switching Capacity104 Gbps176 Gbps (non-blocking)120 Gbps200 Gbps
PoE802.3at/af on 48 ports, 384 W total802.3at/af, up to 30 W per port, 500 W total802.3af/at/bt (Type 3), up to 60 W per port, 200 W total802.3bt on 8 ports (up to 60 W), 802.3at on 16 ports…
PowerInternal; 464.2 W maximum with 384 W of PDsInternal; 49.2 W without PDs, 635.7 W with 500 W of PDsInternal; 244.9 W maximum with 200 W of PDsInternal; 629.1 W maximum with 500 W of PDs
VLAN4K VLANs, voice VLAN, QinQ4K VLANs, private VLAN, voice VLAN, QinQ4K VLANs, private VLAN, voice VLAN4K VLANs, private VLAN, voice VLAN, QinQ

Same on all: Layer · Management

TP-Link S5500-48GP4F questions

Can the S5500-48GP4F power 48 IP phones?

Yes. 384 W averages 8 W per port, more than a typical IP phone needs.

Does the S5500-48GP4F have 10G uplinks?

No, its four uplinks are gigabit SFP. The S5500-48GP4XF has 10G SFP+.
